Smart Peak Flow

U3a1171

About

What is Peak Flow?

Peak flow measurement is a quick test to measure air flowing out of the lungs. The measurement is also called the peak expiratory flow rate (PEFR) or the peak expiratory flow (PEF). Peak flow measurement is mostly done by people who have asthma. During an asthma flare-up, the large airways in the lungs slowly begin to narrow. This slows the speed of air moving through the lungs. A peak flow meter can help show the narrowing of the airways well before an asthma attack happens. A peak flow meter can help you determine:

  • When to get emergency medical care
  • How well an asthma treatment plan is working
  • When to stop or add medicine as directed by your healthcare provider
  • What triggers an asthma attack, such as exercise.
read more about peak flow

Lorem ipsum dolor sit amet, consectetuer adipiscing elit, sed diam nonummy nibh euismod tincidunt ut laoreet dolore magna aliquam erat volutpat.

The Smart Peak Flow is a compact, digital peak expiratory flow meter for respiratory conditions such as asthma.

Using the same technology as a traditional spirometer, the Smart Peak Flow guarantees accurate peak flow measurements and works alongside the Smart Asthma companion app. Smart Peak Flow fits in seamlessly to an asthma management plan, with users recording their peak flow to measure and track asthma symptoms and attacks, as well as predict the likelihood of future exacerbations.

Results can be shared instantly with the user’s physician or respiratory care team and data can be used to determine changes to the user’s asthma management plan.

Product Highlights:

  • Accurately calculates the user’s peak flow readings with medical-grade CE certified sensors
  • The companion app allows users to learn how their asthma reacts to different places, times and activities using the ‘Trigger’ feature
    • Users can easily record their peak flow and add their symptoms, triggers, and environment, as well as record puffer usage
    • Users can track their readings, get personalised charts and tips in the asthma diary
    • Users will be alerted of the increased likelihood of an asthma attack
    • Using colour zones, users can determine if they need medical attention
    • Data can be instantly shared with clinicians
  • The Smart Asthma companion app is available for Android and iOS devices
  • Suitable for ages 5 and above
  • TGA registered.

Software

Patients can download the companion app from Apple and Google.

app store google play

Training

how to use more training materials

Marketing

marketing materials

Warranty

Please follow this link to access the warranty claim procedures documents

Service Warranty Form
Smart Peak Flow devices are covered under warranty for 2 years after date of purchase.
To make a warranty claim or send a device for service, complete the Service Form and follow the instructions on the form for next steps. If in doubt, contact your rep for troubleshooting.

FAQs

Can children use the smart peak flow meter?

The Smart Peak Flow Meter is safe for use for children over 5 years old.

How should patients measure peak flow?

Connect your device to your smartphone and launch the Smart Peak Flow app. Make sure you’re standing in a well-lit area and that you’re not covering the top window. Put the device into your mouth beyond your teeth and close your lips to form a seal around the mouthpiece. Press Start, take a deep breath with your nose and blow as hard and fast as you can out of your mouth. Read the result on your screen and repeat two more times to get a total of 3 measurements – the app will only save the highest.

How can patients download the smart peak flow app?

The app is available for free via the Apple Store and Google Play Store. But, you will need to buy the Smart Peak Flow meter to use the app.

How do patients share peak flow reading with their physician/specialist?

To share their peak flow readings, click on the “share” button near the top left corner of the chart.

Can family members share the smart peak flow device?

The device is designed for use by a single user.

How do patients keep the smart peak flow device clean?
  • We recommend patients clean the mouthpiece and the Smart Peak Flow meter device regularly to maintain the product as it works best when clean. They should also check the mouthpiece and device turbine after each use by looking at it. Make sure that they are clean and clear of foreign objects or substances.
  • Patients can clean both the mouthpiece and device in a bath of lukewarm water. Make sure both are dry before using it again.
  • We also recommend patients keep their Smart Peak Flow device and mouthpiece in the carry bag when not using it.
  • For more information on cleaning, please refer to the section CLEANING AND DISINFECTION in the User Manual.
How long does the Smart Peak Flow Meter last for?

Smart Peak Flow has a guaranteed lifespan of 2 years under normal usage conditions. Perform cleaning of the device on a regular basis to continuously ensure hygienic and accurate measuring.

What does the Smart Peak Flow Package contain?

It consists of the Smart Peak Flow Meter that connects to you smartphone via a 3.5mm headphone jack or Bluetooth, one washable mouthpiece, a drawstring carry bag and the user manual.

Which IOS or Android Versions are supported?

The app works on all phone models with operating system versions of iOS 10 or Android 5.0 and later.

The Bluetooth connection might be problematic for some Huawei phone models dating back to before 2018. To make sure, check with Huawei.

How do I pair the Smart Peak Flow Bluetooth adaptor with my smartphone?
  • To turn the device on, press the button on its face for 3 seconds (you will see three blue flashes of light during these 3 seconds). The device will enter into pairing mode (you will see flashing blue and red lights).
  • Enter the settings menu on your smartphone and find the Bluetooth settings. In the Bluetooth settings, press, Pair new device”. Now wait for SmartPeakFlow” to appear on the list and tap on it. You might get prompted to confirm that you want to Pair the Bluetooth Adapter; if this is the case, press. Pair”. (If the pairing is successful, the ring around the button will show constant blue light) (You will only have to pair the Bluetooth Adapter to your phone once, it will then remember it and automatically connect to your phone the next time you turn it on.)
  • If it presents the following message on the Smart Peak Flow app ‘Okay, let’s go!’, the device has been successfully paired with your smartphone (please ensure Bluetooth is turned on your smartphone (you will see a constant blue light)
  • Now plug your SMART PEAK FLOW device into the Bluetooth Adapter, and you are ready to go!
  • To turn the device off, press the button for 3 seconds (you will see three red flashes of light during these 3 seconds)
  • The device automatically turns off 2 minutes after being turned off to save battery. We recommend turning your device off once you are done with the measurements to preserve the battery further.
  • Charging: Connect the Micro-USB charging cable to the Bluetooth Adapter and the USB of the line to any computer or a wall socket via Wall Adapter. (You will see a constant red light when the device is charging.) The battery charging time from 0 to 100% is approximately 30 minutes. You can use up to 4 hours after a full charge.
How will SPF alert users of an Asthma attack?

Can SPF be helpful with other respiratory conditions?

Peak Flow measurements can also be used to assess other lung problems, such as:

  • Emphysema. This is a chronic lung condition that affects the smallest air sacks in the lungs (alveoli).
  • Chronic bronchitis. This is long-term inflammation of the bronchi. It creates excess mucous and a chronic cough.
  • COPD
Is it normal to get a higher peak flow value compared to the mechanical peak flow meter?

Yes, a difference in readings is expected for first time users. Our peak flow meter was proven to be more accurate than mechanical ones, so there is always a chance that your previous device was not as precise.

If the patient is using a mechanical peak flow meter, it is possible that the internal parts may not be moving as well as they used to, giving a lower result. Conversely, if the internal parts are worn down this could lead to giving higher values.

We recommend patients stick to using one meter for consistent results. This allows users to detect changes in peak expiratory flow (PEF) intensity over a specific period in a reliable way.

Research

SMART PEAK FLOW RESEARCH PAPERS
